View Control Film

View Control Film or VC-Film is an optical louver film of alternating optical clear silicone rubber and black silicone rubber layers used as privacy filter or optical shutter for disturbing reflections.

View Control Film or VC-Film is an optical louver film of alternating optical clear silicone rubber and black silicone rubber layers. Sheets of such alternating layers are positioned between PC or PET films to provide an optical filter.

The highly transparent silicone rubber allows VC-Film to be used in following functional applications:

  • privacy filter for ATM machine, POS terminals, notebook computers and smart phones
    Positioning the View Control Film in front of a display panel with louvers vertical, the film will make the image on the display visible for the user of the display only. People positioned besides the user will not see information on the display. For tablet style handheld devices, filters can be stacked as cross filter to shut lights in all directions. For large size displays or curved displays, louver structures can be optimized towards the view direction.
  • anti-reflection filter for backlit functions in cars
    Positioning the View Control Film in front of a display panel or on a backlit switch, the film will allow the light to go towards the driver. The backlight will be blocked in the direction of the windshield or side windows and stop the mirror image while driving at night. The View Control Film allows cardesigners to freely position functions in the car without requiring special designed roofs to avoid reflections.
  • light shutter for industrial light sensors
    To avoid disturbing effects of light curtains mounted on industrial machines, View Control Film can block light in undesirable directions.

VC-Film is made to custom design and requirements although certain view angles and louver angles are standardized to ease the supply. Special view angles, louver angles, louver pitches, louver colors and constructions are available on request. Full data and examples of designs are in the download files.

VC-Film can be used on top of touchpanels based on capacity touch reading.

Standard VC-Film

Full data in download
Standard TypeView AngleMax total
transmittance
angle
Pitch/mm
VCF132900090°0.132
VCF132600060°
VCF1324800 48°
VCF1329015 90°15°
VCF1326015 60°15°
VCF1324815 48°15°
VCF132902590°25°
VCF132602560°25°
VCF132482548°25°
VCF100900090°0.1
VCF100600060°
VCF100480048°
