SP type of Inter-Connector

The SP-type of Inter-Connector is basically an S-type with both sides softer isolative support material to ease compression and reduce compression force.

The SP-type of Inter-Connector, developed for tall connection height applications, is basically an S-type with both sides softer isolative support material to ease compression and reduce compression force.

The SP-type uses low resistance carbon particle material as conductor to keep the resistance low. Other materials are same as for the SS-type.

SP Type Dimensions

Full data in download
ParameterUnitValue
Pitchmm0.05/ 0.1
Lengthmm2 ~ 270
Heightmm1 ~ 20
Widthmm1.2 ~ 4
Width conductive core mm0.3/ 0.6

SP Type Properties

Full data in download
ParameterUnitValue
Compression set % 12 ~ 20
Volume resistance - conductorΩ.cm1.3
Dielectric breakdown voltage KV/mm
23 ~ 27
Isolation resistance (500V DC) > 10^3
Operating temperature range °C -25 ~ 85
